High Vacuum Rotary Vane - Vacuum Pump
High Vacuum Pumps
High reliability low noise and easy maintenance are the key features of this range, making it particularly suitable for laboratories, research institutes and Universities. This series can also be used as backing pumps on ultra high vacuum units.
APPLICATIONS: LABORATORY, SCIENTIFIC, RESEARCH, ETC
| Pump | Nominal Capacity | Ultimate Pressure † | Ultimate Pressure ♦ | Permissable Water Vapour ♦ | Motor Rating | Noise Level | Weight | Connection |
|---|---|---|---|---|---|---|---|---|
| m3/h | mbar | mbar | kg/h | Kw* | dB(A) | KG | ||
| D 4 B | 4.8 | <0.0001 | < 0.005 | 0.093 | 0.37 | 50/52 | 18 | DN16KF |
| D 8 B | 9.7 | <0.0001 | < 0.005 | 0.157 | 0.37 | 50/52 | 19 | DN16KF |
| D 16 B | 18.9 | <0.0001 | < 0.005 | 0.305 | 0.55 | 54/56 | 27 | DN25KF |
| D 25 B | 29.5 | <0.0001 | < 0.005 | 0.476 | 0.75 | 54/56 | 30 | DN25KF |
| D 40 B | 46.0 | <0.0001 | < 0.005 | 1.184 | 2.20 | 57/59 | 67 | DN40KF |
| D 65 B | 75.0 | <0.0001 | < 0.005 | 1.952 | 2.20 | 57/59 | 83 | DN40KF |
| † | without Gas Ballast | |||||||
| ♦ | with Gas Ballast | |||||||
